WalletConnect Pay via WalletKit - Flutter

dependencies:
  reown_walletkit: ^1.5.1

flutter pub get

import 'package:reown_walletkit/reown_walletkit.dart';

final walletKit = await ReownWalletKit.createInstance(
  projectId: 'YOUR_PROJECT_ID',
  metadata: PairingMetadata(
    name: 'My Wallet',
    description: 'My Wallet App',
    url: 'https://mywallet.com',
    icons: ['https://mywallet.com/icon.png'],
  ),
);

final payClient = walletKit.pay;

if (walletKit.isPaymentLink(uri)) {
  // Handle as payment. See [Get Payment Options] section
} else {
  // Handle as regular WalletConnect pairing
  await walletKit.pair(uri: Uri.parse(uri));
}

dependencies:
  webview_flutter: ^4.10.0
  url_launcher: ^6.1.0

import 'dart:convert';
import 'package:flutter/material.dart';
import 'package:webview_flutter/webview_flutter.dart';
import 'package:url_launcher/url_launcher.dart';

class PayDataCollectionWebView extends StatefulWidget {
  final String url;
  final VoidCallback onComplete;
  final ValueChanged<String> onError;

  const PayDataCollectionWebView({
    super.key,
    required this.url,
    required this.onComplete,
    required this.onError,
  });

  @override
  State<PayDataCollectionWebView> createState() =>
      _PayDataCollectionWebViewState();
}

class _PayDataCollectionWebViewState extends State<PayDataCollectionWebView> {
  late final WebViewController _controller;
  bool _isLoading = true;

  @override
  void initState() {
    super.initState();
    _controller = WebViewController()
      ..setJavaScriptMode(JavaScriptMode.unrestricted)
      ..setNavigationDelegate(NavigationDelegate(
        onPageFinished: (_) => setState(() => _isLoading = false),
        onNavigationRequest: (request) {
          if (!request.url.contains('pay.walletconnect.com')) {
            launchUrl(Uri.parse(request.url),
                mode: LaunchMode.externalApplication);
            return NavigationDecision.prevent;
          }
          return NavigationDecision.navigate;
        },
      ))
      ..addJavaScriptChannel(
        'ReactNativeWebView',
        onMessageReceived: (message) {
          try {
            final data = jsonDecode(message.message) as Map<String, dynamic>;
            switch (data['type']) {
              case 'IC_COMPLETE':
                widget.onComplete();
                break;
              case 'IC_ERROR':
                widget.onError(data['error'] ?? 'Unknown error');
                break;
            }
          } catch (_) {}
        },
      )
      ..loadRequest(Uri.parse(widget.url));
  }

  @override
  Widget build(BuildContext context) {
    return Stack(
      children: [
        WebViewWidget(controller: _controller),
        if (_isLoading)
          const Center(child: CircularProgressIndicator()),
      ],
    );
  }
}

import 'package:reown_walletkit/reown_walletkit.dart';

class PaymentService {
  final ReownWalletKit walletKit;

  PaymentService(this.walletKit);

  /// Process a payment from a payment link (e.g., after scanning QR code)
  Future<void> processPayment(String paymentLink) async {
    try {
      // Step 1: Get payment options
      final accounts = await getWalletAccounts(); // Your wallet accounts
      final optionsResponse = await walletKit.getPaymentOptions(
        request: GetPaymentOptionsRequest(
          paymentLink: paymentLink,
          accounts: accounts,
          includePaymentInfo: true,
        ),
      );

      if (optionsResponse.options.isEmpty) {
        throw Exception('No payment options available');
      }

      // Step 2: Select payment option (or let user choose)
      PaymentOption selectedOption = optionsResponse.options.first;
      final paymentId = optionsResponse.paymentId;
      final optionId = selectedOption.id;

      // Step 3: Collect data via WebView if required for selected option.
      // This must happen BEFORE fetching the required payment actions —
      // the backend rejects the actions request with 400 "IC data required"
      // for options needing Information Capture if data wasn't collected first.
      // The WebView submits the data directly to the backend, so it is NOT
      // passed to confirmPayment later.
      if (selectedOption.collectData?.url != null) {
        await showDataCollectionWebView(selectedOption.collectData!.url);
      }

      // Step 4: Get required payment actions (if not already in the option)
      List<Action> actions = selectedOption.actions;
      if (actions.isEmpty) {
        actions = await walletKit.getRequiredPaymentActions(
          request: GetRequiredPaymentActionsRequest(
            optionId: optionId,
            paymentId: paymentId,
          ),
        );
      }

      // Step 5: Execute wallet actions and collect the results
      final data = <Object>[];
      for (final action in actions) {
        // Dispatch based on action.walletRpc.method:
        // 'eth_signTypedData_v4' -> sign EIP-712 typed data
        // 'eth_sendTransaction'  -> send transaction (e.g., token approval)
        // 'personal_sign'        -> personal message signing
        data.add(await signAction(action.walletRpc));
      }

      // Step 6: Confirm payment
      ConfirmPaymentResponse confirmResponse = await walletKit.confirmPayment(
        request: ConfirmPaymentRequest(
          paymentId: paymentId,
          optionId: optionId,
          data: data,
          maxPollMs: 60000, // Maximum polling time in milliseconds
        ),
      );

      // Step 7: Poll until final status (if needed)
      while (!confirmResponse.isFinal && confirmResponse.pollInMs != null) {
        await Future.delayed(Duration(milliseconds: confirmResponse.pollInMs!));
        confirmResponse = await walletKit.confirmPayment(
          request: ConfirmPaymentRequest(
            paymentId: paymentId,
            optionId: optionId,
            data: data,
            maxPollMs: 60000,
          ),
        );
      }

      // Handle final payment status
      switch (confirmResponse.status) {
        case PaymentStatus.succeeded:
          print('Payment succeeded!');
          break;
        case PaymentStatus.failed:
          throw Exception('Payment failed');
        case PaymentStatus.expired:
          throw Exception('Payment expired');
        case PaymentStatus.cancelled:
          throw Exception('Payment cancelled');
        case PaymentStatus.requires_action:
          throw Exception('Payment requires additional action');
        case PaymentStatus.processing:
          // Should not happen if isFinal is true
          break;
      }
    } catch (e) {
      print('Payment error: $e');
      rethrow;
    }
  }

  Future<List<String>> getWalletAccounts() async {
    // Return your wallet's CAIP-10 formatted accounts
    // Example: ['eip155:1:0x1234...', 'eip155:137:0x5678...']
    return [];
  }
}

GetPaymentOptionsRequest({
  required String paymentLink,
  required List<String> accounts,
  @Default(false) bool includePaymentInfo,
})

PaymentOptionsResponse({
  required String paymentId,
  PaymentInfo? info,
  required List<PaymentOption> options,
  CollectDataAction? collectData,
  PaymentResultInfo? resultInfo,     // Transaction result details (present when payment already completed)
})

class PaymentResultInfo {
  final String txId;               // Transaction ID
  final PayAmount optionAmount;    // Token amount details
}

PaymentInfo({
  required PaymentStatus status,
  required PayAmount amount,
  required int expiresAt,
  required MerchantInfo merchant,
  BuyerInfo? buyer,
})

PaymentOption({
  required String id,
  required String account,
  required PayAmount amount,
  @JsonKey(name: 'etaS') required int etaSeconds,
  required List<Action> actions,
  CollectDataAction? collectData,  // Per-option data collection (null if not required)
})

ConfirmPaymentRequest({
  required String paymentId,
  required String optionId,
  List<Object>? data,                   // Wallet RPC results in action order: Strings or Map<String, dynamic> JSON objects
  @Default([]) List<String> signatures, // Deprecated alias for `data`, still accepted as fallback when data is null
  int? maxPollMs,
})

ConfirmPaymentResponse({
  required PaymentStatus status,
  required bool isFinal,
  int? pollInMs,
  PaymentResultInfo? info,           // Transaction result details (present on success)
})

enum PaymentStatus {
  requires_action,
  processing,
  succeeded,
  failed,
  expired,
  cancelled,
}

class CollectDataAction {
  final String url;                // WebView URL for data collection
  final String? schema;            // JSON schema describing required fields
}

abstract class PayError extends PlatformException {
  PayError({
    required super.code,
    required super.message,
    required super.details,
    required super.stacktrace,
  });
}

try {
  final response = await walletKit.getPaymentOptions(request: request);
} on GetPaymentOptionsError catch (e) {
  print('Error code: ${e.code}');
  print('Error message: ${e.message}');
} on PayError catch (e) {
  // Catch any Pay-related error
  print('Pay error: ${e.message}');
} catch (e) {
  print('Unexpected error: $e');
}
